Maxhub U30 Series Interactive Flat Panel Smart Board
₨ 220,000.00 – ₨ 290,000.00
Description
MAXHUB U3 Series Overview
The MAXHUB U3 Series is an advanced interactive flat panel designed for smart classrooms, training institutes, and modern workspaces. With 4K Ultra HD display, AI-powered performance, Google EDLA certification, and intelligent audio-video systems, it offers a seamless teaching, collaboration, and presentation experience. It’s available in 65″, 75″, and 86″ sizes.
📋 Detailed Specification Table
| Category | Specification |
|---|---|
| Model Sizes | Â 75″ (U7530), 86″ (U8630) |
| Display Resolution | 4K UHD (3840 × 2160) |
| Panel Type | VA with DLED Backlight |
| Brightness | 450 nits (65″), 500 nits (75″, 86″) |
| Color Gamut | 72% NTSC |
| Color Accuracy | ΔE ≤ 1.5 |
| Color Depth | 10-bit, 1.07 Billion Colors |
| Contrast Ratio | 5000:1 |
| Response Time | 6.5 ms |
| Touch Technology | Infrared, 50-point multi-touch |
| Touch Accuracy | ±0.5 mm with Palm Rejection |
| Touch Features | Low latency, Pressure sensitivity |
| Operating System | Android 13.0 (dual system support with optional OPS PC) |
| Processor (CPU) | Octa-core (4×A76 + 4×A55) |
| GPU | Mali-G610 MP4 |
| AI Processor (NPU) | 6 TOPS (supports AI tasks like voice, transcription, and visual enhancement) |
| RAM | 8 GB |
| Internal Storage | 64 GB |
| Certification | Google EDLA Certified (Play Store + Google Classroom & Drive access) |
| Speakers | 2 × 8W + 2 × 18W (2.2 Channel Audio) |
| Microphones | 8-array mic, up to 10-meter voice pickup |
| Audio Features | Echo cancellation, beamforming, immersive clarity |
| USB-C Port | 100W PD, video, audio, touch, network over single cable |
| Connectivity Ports | HDMI, DP, USB-A/B/C, LAN, Audio, RS232 |
| Wireless Casting | Yes, built-in and seamless BYOD (multi-platform support) |
| Multi-Display Support | Yes |
| Eye Protection | TÃœV-certified Flicker-Free and Low Blue Light |
| Antibacterial Glass | Optional with SGS, SIAA, and TÃœV certifications |
| Software Suite | MAXHUB EDU OS, Class/Class Pro, Pivot for IT management |
| Included Accessories | Power Cord, HDMI Cable, USB Touch Cable, Remote, Stylus, Wall Mount, Wi-Fi Module |
| Optional Add-ons | Slot-in OPS PC, Antibacterial Glass, PTZ Camera, Trolley/Stand |
Additional information
| size | 75inch, 86inch |
|---|
